I have seen too many DIYers try to turn IKEA Billy bookcases into custom built-ins, only to end up with wobbly shelves and ugly gaps. You do not need to make those same mistakes. Learning how to make built-in bookshelves from IKEA Billy bookcases is actually simple if you know where most people slip up. This guide walks you through the five biggest errors and exactly how to avoid them, so your weekend project looks like a professional carpenter did it.
Choosing the Right Billy Bookcases for Your Space
A common mistake is grabbing the wrong depth or height. Billy comes in two depths: 28cm and 40cm. For a built-in look next to a wall with standard baseboards, the 28cm (narrow) version often sits too far forward, requiring extra filler. The 40cm depth usually matches better. Also, mix heights carefully: a 202cm tall Billy beside a 106cm half-height unit can create an odd step if you do not plan the crown molding line. Stick to one height across your built-in run, or use the height extension units to match.
Another error is buying the standard white finish and expecting paint to stick without proper prep. The glossy foil surface does not hold paint well. Choose the pre-primed wood-effect Billy (often called “Birch” or “Beech” effect) if you plan to paint. It is a solid fiberboard that sands and primes beautifully. If you already have white gloss ones, plan to sand thoroughly and use a high-bond primer.
Measuring and Planning to Avoid Gaps
Gaps between the bookcases and the wall are the number one giveaway that it is not a real built-in. Measure your wall width and the combined width of your Billy units. A single Billy is 80cm wide, but the actual width can vary by a few millimeters due to manufacturing tolerances. Always measure each individual unit after assembly, not just the box dimensions. Then cut filler strips from MDF to fill any leftover space. I cut mine about 2mm wider than measured, then plane or sand them flush.
Do not forget to account for baseboard trim. If you push the bookcases tight against the wall, the baseboard will leave a gap at the back. Either remove the baseboard in that section or cut notches into the back of the Billy unit. Notching is easier: mark the baseboard height, cut a groove in the back panel with a jigsaw, and slide the unit over the trim. This gives a tight fit to the wall.
Securing the Bookcases to Each Other and the Wall
Many people screw two Billy units together using the factory-provided holes on the sides. That works, but the holes are small and the screws strip easily. A better method is to clamp the units together first, then drill your own pilot holes through both side panels. Use 30mm wood screws with a countersink bit. Place at least three screws vertically near the top, middle, and bottom. Also secure the bottom to the floor with L-brackets if you have no baseboard gap.
Securing to the wall is non-negotiable. Billy bookcases are tall and thin; they tip forward. Use the included wall straps, but replace the cheap plastic anchors with proper toggle bolts or metal anchors rated for the weight of books. Drill into studs if possible. If you cannot hit a stud, use heavy-duty hollow-wall anchors. A fully loaded Billy can weigh over 50kg. Do not skip this step.
Adding Crown Molding Without the Headache
Crown molding on a flat-topped Billy bookcase is the trickiest part. The mistake is trying to miter the corners without a flat reference. Billy tops are not perfectly square; they bow slightly. First, shim the units so the tops are level both front-to-back and side-to-side. Then attach a continuous strip of 1×2 lumber across the top of all the units. This creates a nailing surface for the crown. Screw the 1×2 into the top edges of the Billy through the top panel (drill pilot holes).
Cut the crown molding using a coping saw for inside corners rather than trying to miter tight 45-degree angles. Because Billy tops are not perfectly square, miters rarely line up. Coping gives a cleaner joint. Nail the crown into the 1×2 strip, not into the thin Billy top itself. Fill nail holes with spackle, sand smooth, and paint. This technique hides any unevenness in the unit tops.
Painting Billy Bookcases for a Seamless Finish
Skipping primer is the fastest way to ruin your built-in look. The factory coating on Billy cases repels paint. Without primer, the paint beads up and peels off with the first bump. Sand the entire surface with 120-grit sandpaper, then wipe clean. Apply a shellac-based primer (Zinsser BIN works great) or a high-adhesion latex primer. Two coats of primer are better than one, especially on the edges and shelves.
For the topcoat, use a matte or satin interior paint. Roller with a low-nap sleeve gives a smooth finish if you do not overload the roller. Brush the corners and edges carefully. Do not paint the shelves while they are installed; take them out, paint them separately, and let them cure for 24 hours. This avoids drips and stuck shelves. Match the paint to your wall color exactly. I take a chip of my wall paint to the store and have it color-matched in the same sheen.
Common Trim and Filler Mistakes
People often forget to fill the gap between the top of the bookcases and the ceiling. Even a 1cm gap ruins the illusion. If your ceiling is not perfectly flat (and it is not), cut a thin strip of MDF or plywood to fill the gap. Nail it to the top of the 1×2 base you installed for the crown, then caulk the joint. Paint it all together. Also, use quarter-round or shoe molding along the bottom front edge where the bookcases meet the floor. It hides uneven floor lines and gives a finished base.
Another overlooked area is the gap where two Billy units meet. Even after screwing them tightly, you may see a tiny seam. Fill that seam with wood filler, let dry, sand, and paint. Use a flexible caulk for corners where the filler might crack from seasonal movement. Do not leave raw edges: the side panels of Billy are unfinished particleboard. Apply a thin strip of veneer tape or paint the edge before pushing units together.
Final Assembly Order Matters
I see people assemble all the Billy units in place on the floor, then try to lift them upright. That is heavy and dangerous. Instead, build each unit on its side on a protected floor, attach the back panel with the small nails (use a screw gun to pre-drill), then stand each one up individually. Slide them into position before attaching them to each other. Level each unit from side to side with a long level. Shim under the feet if needed. Only after all units are level and aligned should you screw them together and secure to the wall.
One last tip: install the doors (if you use them) after the units are fixed. Doors from Billy are hinged on the side and can swing into walls or other units. Adjust the hinges after the crown molding is done. Also, if you want a truly custom look, consider adding a solid wood face frame to the front edges. That requires more woodworking skill, but it hides the Billy gaps completely. Most people skip that and just caulk and paint, which works well if you are careful.
Building custom built-in bookshelves from IKEA Billy bookcases is totally doable as a weekend project, but the difference between a professional result and a messy one comes down to avoiding these common mistakes. Plan your measurements, prep your surfaces, secure everything solidly, and take time on the molding and painting. Save this guide for your next home upgrade, and you will end up with shelves that look like they were built exactly for your room.
